Looking for power, versatility and reliability? Look no further. Following in the footsteps of its predecessor, the S925TX mini skid steer from Vermeer has the toughness to work through your toughest challenge. With impressive lift capacity and the comfort of a chariot-style operating station, this machine is designed for productivity and comfort. The standard dual auxiliary hydraulic system works in tandem with the universal mounting plate to provide maximum versatility on the jobsite.
S925TX Mini Skid Steer
REQUEST OFFER
Let us help you get the job done efficiently and effectively!
Features & Benefits
1
Though compact and nimble, the S925TX still delivers an impressive ROC of over 950 lb (431 kg).
2
The S925TX features a standard dual hydraulic system with high flow to power the most demanding attachments and low flow for maximum control.
3
The S925TX features a universal mounting plate and offers multiple engine choices, all designed to enhance job site productivity.
4
With options for either wide or narrow tracks, the S925TX can be configured to fit your needs for both access and reduced ground pressure.
5
Single, pilot-operated joystick provides the operator with a smooth range of operation, eliminating the need to balance two separate controls.
6
The integrated operator presence system suspends ground drive and powered boom/bucket motion when the operator steps off the platform.
Units:
SPECIFICATIONS
-
Ground Clearance6 in
-
Width Without Standard Bucket36 in
-
Length with Standard Bucket106 in
-
Length without Standard Bucket84 in
-
Weight (Standard Bucket, Diesel Engine)3465 lbs
-
Height58 in
-
Weight (No Bucket, Diesel Engine)3350 lbs
-
Height (to Hinge Pin)84.5 in
-
Width with Standard Bucket42 in
-
DesignStand-on/Track drive
-
Make and ModelKubota V1505
-
Fuel Tank Capacity13 gal
-
Gross Horsepower24.8 hp
-
Fuel TypeDiesel
-
Cooling SystemLiquid
-
Maximum Angle of Inclination30 deg
-
Travel Speed4.1 mph
-
Fuel TypeDiesel
-
Make and ModelKubota V1505 (available in LRC only)
-
Gross Horsepower35 hp
-
Fuel Tank Capacity13 gal
-
Cooling SystemLiquid
-
Maximum Angle of Inclination30 deg
-
Travel Speed4.5 mph
-
Make and ModelKubota V1505
-
Fuel TypeGas
-
Fuel Tank Capacity13 gal
-
Gross Horsepower (Maximum)40 hp
-
Cooling SystemLiquid
-
Maximum Angle of Inclination30 deg
-
Travel Speed4.5 mph
-
Rated Operating Capacity (SAE)925 lbs
-
Ground Pressure (Narrow Tracks)5 psi
-
Ground Pressure (Wide Tracks)4 psi
-
CurlDual Axis, common bucket lever
-
SteeringDual Axis, pilot operated joystick
-
LiftDual Axis, common bucket lever
-
Hydraulic System Pressure3045 psi
-
Tank capacity10.5 gal
-
Hydraulic System Flow12 gpm
