HG6000 European Configuration
  • Bring more versatility to your wood waste processing operation
  • Maintenance-friendly design optimizes serviceability
  • Equipped with Vermeer innovations to help protect your investment and optimize efficiency
REQUEST OFFER

Let us help you get the job done efficiently and effectively!

HG6000 European Configuration
HG6000 European Configuration - Image 2

Features & Benefits

1

Maximize loading speed and productivity using the patented SmartGrind system and hydraulic feed roller down pressure. Open-ended, wide infeed tables are designed to make over-the-side loading easy and efficient.

2

The Series III duplex drum is built off the proven cutting performance of previous Vermeer duplex drum designs and makes maintenance more convenient with enhancements such as an independently secured wedge system and enhanced drum balancing.

3

A 60-in (152.4-cm) wide infeed table with flared sidewalls can accommodate a large volume of material.

4

The intelligent feed system monitors the machine's engine speed, and holds the engine at an optimal level. This allows you to spend more time feeding and less time adjusting settings.

5

Machine damage caused by metal contaminants entering the hammermill can be costly. The Vermeer Damage Defense system helps protect your machine by detecting certain metal contaminants.

6

An industry-leading, full-function, wireless remote control lets you adjust machine settings from the cab as conditions change, including control of the infeed settings, engine droop, conveyor height and more.

7

The feed roller planetary is fully enclosed for protection from debris and offers a tighter clearance between the feed roller and mill housing, helping reduce material blockage and drag on the feed roller circuit.

8

Reduce the quantity and distance of thrown material debris with the Thrown Object Deflector (TOD), strategically placed to reduce interference when loading over-length material.

Units:

SPECIFICATIONS

  • Maximum Length (Operation)
    53 ft
  • Maximum Width (Transport)
    8.2 ft
  • Maximum Height (Transport)
    13.1 ft
  • Maximum length - Transport (5th wheel)
    38.8 ft
  • Maximum tongue weight (5th wheel)
    19841.6 lbs
  • Maximum axle weight (5th wheel)
    44092.4 lbs
  • Make and Model
    CAT C18 T4F/Stage V
  • Number of Cylinders
    6
  • Gross Horsepower (Maximum)
    755 hp
  • Torque (Max)
    2582 ft-lb
  • Fuel Tank Capacity
    350 gal
  • Max Fuel Consumption
    37.9 gph
  • Fuel Type
    Ultra-low sulfur diesel (<15 ppm)
  • Air Cleaner
    Dry-type with primary and secondary elements and restriction indicator
  • Oil Filter
    Full-flow spin-on
  • Recommended Oil
    API CJ-4, ECF-3, or API CK-4 Ultra Low Sulfur. Varying viscosity based on ambient conditions.
  • Oil Volume with Filter
    35.9 qt
  • Cooling Medium
    Liquid (nitrite-free, pre-diluted 50/50)
  • Coolant Capacity (Engine and Radiator)
    28.7 gal
  • Air to Boil Temperature
    124 deg
  • Alternator
    24 V 95 A
  • Fan
    Hydraulically-driven, reversible
  • Clutch Type
    Hydraulic-operated wet clutch, PT Tech
  • Clutch Engagement
    Push buttons
  • Drive Belt Type
    Synchronous
  • Sound Power
    121 dB(A)
  • Oil volume with filter
    9 gal
  • Fan - CAC
    Hydraulically-driven, reversible
  • Make and Model
    CAT C18 T4i
  • Number of Cylinders
    6
  • Gross Horsepower (Maximum)
    755 hp
  • Torque (Max)
    2582 ft-lb
  • Fuel Tank Capacity
    350 gal
  • Max Fuel Consumption
    37.9 gph
  • Fuel Type
    Ultra-low sulfur diesel (<15 ppm)
  • Air Cleaner
    Dry-type with primary and secondary elements and restriction indicator
  • Oil Filter
    Full-flow, spin-on
  • Recommended Oil
    API CJ-4, ECF-3, or API CK-4 Ultra Low Sulfur. Varying viscosity based on ambient conditions.
  • Oil Volume with Filter
    35.9 qt
  • Cooling Medium
    Liquid (nitrite free, pre-diluted 50/50)
  • Coolant Capacity (Engine and Radiator)
    28.7 gal
  • Air to Boil Temperature
    124 deg
  • Alternator
    24 V 95 A
  • Fan
    Hydraulically-driven, reversible
  • Clutch Type
    Hydraulic-operated wet clutch, PT Tech
  • Clutch Engagement
    Push button
  • Drive Belt Type
    Synchronous
  • Sound Power
    Standard exhaust: 121 dB(A); Deluxe exhaust: 120 dB(A)
  • Fan - CAC
    Hydraulically-driven, reversible
  • Make and Model
    CAT C18 T3/Stage IIIA
  • Number of Cylinders
    6
  • Gross Horsepower (Maximum)
    630 hp
  • Torque (Max)
    2042 ft-lb
  • Fuel Tank Capacity
    350 gal
  • Max Fuel Consumption
    32.9 gph
  • Fuel Type
    Diesel
  • Air Cleaner
    Dry-type with primary and secondary elements and restriction indicator
  • Oil Filter
    Full-flow, spin-on
  • Recommended Oil
    Varying viscosity based on ambient conditions
  • Oil Volume with Filter
    35.9 qt
  • Cooling Medium
    Liquid (nitrite free, pre-diluted 50/50)
  • Coolant Capacity (Engine and Radiator)
    28.7 gal
  • Air to Boil Temperature
    151 deg
  • Alternator
    24 V 95 A
  • Fan
    Hydraulically-driven, reversible
  • Clutch Type
    Hydraulic-operated wet clutch, PT Tech
  • Clutch Engagement
    Push button
  • Drive Belt Type
    Synchronous
  • Sound Power
    Standard exhaust: 122 dB(A); Deluxe exhaust: 122 dB(A)
  • Thrown Object Deflector
    Standard
  • Deflector Position
    Variable
  • Curtain description
    Rubber
  • Tip Diameter
    36.4 in
  • Millbox Opening
    60-in (150-cm) wide x 32-in (81-cm) high
  • Drum Diameter
    28 in
  • Drum Cutting Width
    62.4 in
  • Drum Skin Thickness
    1.5 in
  • Drum Speed
    1171 rpm
  • Bearing Type
    Double row spherical roller
  • Bearing - Inner Race Diameter
    5.5 in
  • Bearing - Dynamic Capacity
    166000 lbs
  • Number of Hammers
    10
  • Number of Tips
    20
  • Center Retention Pin Dimensions
    2-in (5-cm) diameter x 75.3-in (191-cm) length
  • Number of Wipers
    None
  • Drum Weight
    4741 lbs
  • Tip speed (Duplex)
    11168 ft/min
  • Tip types
    Premium wide
  • Drum Cutting Width
    62.4 in
  • Drum Diameter
    34.3 in
  • Drum Skin Thickness
    1.5 in
  • Drum Speed
    683 rpm
  • Bearing Type
    Double row spherical roller
  • Bearing - Inner Race Diameter
    5.5 in
  • Bearing - Dynamic Capacity
    166000 lbs
  • Drum Weight
    5946 lbs
  • Depth of Cut
    Adjustable: .125 in (.318 cm) to 1.5 in (3.8 cm)
  • Number of Knives
    28
  • Knife Thickness
    .625 in (1.59 cm)
  • Useable Edges
    1
  • Material
    A8 mod chipper steel
  • Number of Bolts/Knife
    2
  • Replaceable Threaded Knife Block
    Yes
  • Number of Pockets
    14
  • Tip speed (1-in chip)
    6673 ft/min
  • Shaft diameter
    6.5 in
  • Shaft Retention Type
    Keyless bushing
  • Number of Screens
    2
  • Screen Dimensions
    .75-in (1.9-cm) thick
  • Screen Type
    Abrasion-resistant steel
  • Screen Area
    3317 sq in
  • Anvil Type
    Fabricant steel with replaceable wear surfaces
  • Millbox lid liner
    Abrasion-resistant steel
  • Splice
    R2-stainless steel cable or Super Splice
  • Length
    81.3 ft
  • Width
    48 in
  • Belt Design
    3 ply - 330# or straight warp single ply 330# both with V cleat
  • Return Roller Quantity
    4
  • Idler Roller Diameter
    12 in
  • Idler Roller Bearing
    1-15/16, 4-bolt flange
  • Standard Drive Roller Diameter
    12.8 in
  • Magnetic Drive Roller Diameter
    12.8 in
  • Drive Motor
    Fixed displacement
  • Belt Speed
    780 ft/min
  • Load Height
    14 ft
  • Number of Coolers
    2
  • Tank capacity
    100 gal
  • Recommended Oil
    Vermeer HyPower 68
  • Filtration Method
    Dual in-tank return filters (B5=200)
  • Components
    Dual proportional control valves
  • System Type
    Open-loop, pressure and flow compensated
  • Pump Type
    Variable displacement, axial piston
  • Pump Flow at Maximum RPM
    32.4 gpm (123 L/min)
  • System Relief Pressure
    4000 psi (276 bar)
  • System Relief Pressure
    3000 psi (207 bar)
  • System Type
    Open-loop
  • Pump Type
    Fixed displacement, gear
  • Pump Flow at Maximum RPM
    25.7 gpm
  • Motor Series
    Fixed displacement, geroler
  • Motor Series
    Fixed displacement, gear
  • System Type
    Open-loop, pressure and flow compensated
  • Pump Type
    Variable displacement, axial piston
  • Pump Flow at Maximum RPM
    36.2 gpm
  • Fan Series - FWD/REV
    Reversible
  • Number of Coolers
    1
  • Tank capacity
    18 gal
  • Recommended Oil
    VMF Gold
  • Filtration Method
    Spin-on, pressure filter (B6=1000)
  • System Type
    Open-loop
  • Pump Type
    Fixed displacement, gear pump
  • Pump Flow at Maximum RPM
    12.4 gpm
  • System relief pressure
    260 psi
  • System Voltage
    24 V
  • Battery
    Group 8-D, 1155 CCA (qty. 2)
  • System Protection
    Fused
  • Operational Faults
    Yes
  • Display Type
    LCD
  • Engine Information
    Yes
  • Machine Information
    Yes
  • Gauges
    Two: fuel level and hydraulic pressure
  • Switches
    Moisture-proof, toggle style
  • Display Type
    LCD
  • Engine Information
    Yes
  • Machine Information
    Yes
  • Operational Faults
    Yes
  • Switches
    Sealed membrane
  • Operating Range
    300 ft (91.4 m)
  • Battery Type
    AA (qty. 6)
  • Channel Setting
    50 channels
  • Fender Description
    Formed steel, replaceable
  • Frame Description
    Unit body construction
  • Tongue Description
    Integrated into infeed structure
  • Hitch Type
    5th wheel
  • Brake Type
    Air-actuated with spring-applied parking brake
  • Trailer Light Type
    12-24V LED
  • Suspension Type
    Spring
  • Capacity per Axle
    18740 lbs
  • Tires - Option One
    385/65R22.5
  • Wheels - Option One
    Aluminum 22.5x12.25
  • Ground Clearance - Option One
    15.9 in
  • Tires - Option Two
    445/50R22.5
  • Wheels - Option Two
    Aluminum 22.5x14
  • Ground Clearance - Option Two
    14.9 in
  • Number of axles (5th wheel)
    3
  • Maximum Air Flow
    29 cfm
  • Engine
    11.7 hp (8.72 kW)
  • Maximum Pressure
    175 psi
  • Tank capacity
    30 gal
  • Preventative Maintenance
    Yes
  • Screens
    Yes
  • Special Tools Group
    Yes
  • Extended Warranty
    Yes
  • Special Paint
    Yes
  • Air Compressor
    Yes
  • Tips
    Yes
  • Magnetic discharge conveyor pulley
    Yes
  • Vermeer Confidence Plus Asset Protection Program
    Yes
  • Damage Defense
    Yes
  • Feed Table Width
    60 in
  • Feed Table Depth
    26.3 in
  • Feed Table Length - Option One
    20 ft
  • Feed Table Capacity
    8.7 cu yd
  • Loading Height
    8.5 ft
  • Flare Construction
    Integrated with infeed
  • Feed Conveyor Type
    Weld slate chain
  • Material Construction
    Steel
  • Material Construction - Option Two
    Grade 50 steel
  • Drive Type
    Radial piston motor
  • Drive Roller Construction
    Welded steel
  • Front Idler Roller Construction
    Self-cleaning steel auger
  • Infeed Floor Construction
    Welded steel with replaceable UHMW wear plates
  • Infeed Roller Width
    56 in
  • Infeed Roller Diameter
    36 in
  • Maximum Feed Height
    47 in
  • Material Type
    Fabricated steel
  • Tooth Design
    Serrated bars
  • Number of Teeth
    13
  • Drive Motor
    Fixed displacement motor/planetary
  • Drive Planetary
    Two options: heavy-duty - 26.18:1; Standard - 34.2:1
  • Feed Roller Down Pressure
    Adjustable
  • Infeed roller weight with arm
    3350 lbs
