Mud Motor – 8” 7/8 Lobe 3.0 Stage – Dev

Let us help you get the job done efficiently and effectively!

Mud Motor – 8” 7/8 Lobe 3.0 Stage

Responsive Table

Parameter	Imperial	Metric
Normal OD	8 in	203 mm
Bit to Centre of Stabiliser Blade A	30.9 in	785 mm
Bit to Bend B	91.7 in	2330 mm
Overall length C	23.95 ft	7.3 m
Weight	3175 lb	1440 Kg
Top connection	6-5/8 Reg
Bottom connection	6-5/8 Reg
Flow Rate	301-599 gpm	1140-2270 lpm
Speed	69-140 rpm
Speed per unit volume	0.233 r/g	0.061 r/l
Max. pressure	491 psi	3.39 Mpa
Max. pressure torque	6444 ft.lb	8736 N.m
