Mud Motor – 4 ¾” 7/8 Lobe 3.0 Stage

Responsive Table

Parameter	Imperial	Metric
Normal OD	4 3/4 in	120 mm
Bit to Centre of Stabiliser Blade A	18.9 in	480 mm
Bit to Bend B	51.6 in	1310 mm
Overall length C	17.71 ft	5.4 m
Weight	837 lb	380 Kg
Top connection	3-1/2 IF, 3-1/2 Reg
Bottom connection	3-1/2 Reg
Flow Rate	100-251 gpm	380-950 lpm
Speed	71-177 rpm
Speed per unit volume	0.708 r/g	0.187 r/l
Max. pressure	491 psi	3.39 Mpa
Max. pressure torque	2125 ft.lb	2881 N.m
